TG-T1000 Thermal Tape
- Features
- Good adhesion(Acrylic PSA)
- Great reliability
- Cost effective with great performance
- Easy to assemble
- Customization services for different industries
It has high thermal conductivity, viscosity and low thermal resistance. It is a good replacement for thermal grease as the high viscosity can fix the electronic parts, which is also a great material for fill up the uneven surface between the heat source and heat sink , to transfer the heat to the heat sink finally achieve heat dissipation and lower the product’s temperature.
Application：
Electronic components - 5G, Aerospace, AI, AIoT, AR/VR/MR/XR, Automotive, Consumer Devices, Datacom, Electric Vehicle, Electronic Products, Energy Storage, Industrial, Lighting Equipment, Medical, Military, Netcom, Panel, Power Electronics, Robot, Servers, Smart Home, Telecom, etc.
-
Thermal Conductivity
Thermal conductivity refers to the ability of a given material to conduct/transfer heat. -
Dielectric Breakdown Voltage
Dielectric breakdown is the failure of an insulating material to prevent the flow of current under an applied electrical stress.
Properties
Unit
TG-T1000 Thermal Tape
Testing methods
Thermal Conductivity
W/m•K
1±10%
ASTM D5470 Modified
Thickness
mm
0.15/0.25
ASTM D374
Color
White
–
Dielectric Breakdown Voltage (AC)
KV
≥3/≥6
ASTM D149
Dielectric Breakdown Voltage (DC)
KV
-
ASTM D149
Operating Temperature
°C
-30~+120
–
Density
g/cm³
1.2
ASTM D792
Reinforcement Carrier
Fiberglass mesh
–
Tensile Strength
psi
-
ASTM D412
Short Time Use Temperature (30sec)
°C
180
–
Glass Transition Temperature
°C
-
–
Initial Tack
cm
19/11
PSTC-6
Lap Shear Strength
N/cm²
-
ASTM D1002
Die Shear Strength @25°C
N/cm²
-
–
Die Shear Strength @80°C
N/cm²
-
–
Holding Power1000g @25°Cusing 1 in²
min
>3000
PSTC-7
Holding Power1000g @80°Cusing 1 in²
min
-
PSTC-7
Peeling Strength 90° (Aluminum)
N/in
-
ASTM D3330
Peeling Strength 180° (Aluminum)
N/25mm
>14/>16
PSTC-101
Thermal Impedance @10psi
°C*in²/W
0.93/1.26
ASTM D5470 Modified
Thermal Impedance @30psi
°C*in²/W
0.76/1.06
ASTM D5470 Modified
Thermal Impedance @50psi
°C*in²/W
0.61/1.05
ASTM D5470 Modified
